Stable Ultra Bright Green Small 7 Segment Led Display IC Compatible

Name: Stable Ultra Bright Green Small 7 Segment Led Display IC Compatible
Brand: LIGHTBO
Price: 1 USD

Buy cheap Stable Ultra Bright Green Small 7 Segment Led Display IC Compatible product

Brand Name : LIGHTBO

Model Number : LB30521XJ0S

Certification : RoHS&SGS&ISO

Place of Origin : Shenzhen,China

MOQ : 1000PCS

Price : negotiable

Payment Terms : TT in advance& Western Union

Supply Ability : 50000PCS/Day

Delivery Time : 10-15Days

Packaging Details : EPE+CARTON

outer dimension : 38.5x19X8mm

digit height : 0.52 inch (13.2mm)

Polarity : common anode

colour : Super green

Contact Now

Stable Ultra Bright Green Small 7 Segment Led Display IC Compatible

Description:
Character height: 0.52 inches (13.2mm)
Outer dimensions: 38.5 x 19 x 8mm
Polarity: common anode
Made with white segments and gray surface
Emitting colors: red , blue , green , white , amber , yellow and orange

Feature:
High luminous intensity
Low power consumption
Extremely low current
Stable performance
Good consistency
Big viewing angle
Longe lifetime
IC Compatible
Easy assembly
Meet RoHS Compliant

Applications:
Audio equipments or instrument panels
Home electronic appliances and air conditioner controllers
General use for digital indicators
Multimedia products
Absolute Maximum Ratings(Ta=25℃)

Parameter	Symbol	Ratings	Unit
Forward Current(per dice)	Ipm	20	mA
Reverse Voltage(per dice)	Vr	5	V
Power Dissipation(per dice)	Pm	80	mW
Operating Temperature Range	Topr	-40～+85	℃
Storage Temperature Range	Tstg	-40～+85	℃
Solder Temperature(3 sec)	Th	260	℃

Code:J-Ultra Bright Green

Parameter	Sym bol	Condition	Min	Typ	Max	Unit
Forward Voltage(Per dice)	Vf	If=20mA	1.8		2.5	V
Reverse Voltage(Per dice)	Vr	Ir=10uA		5		V
Luminous Intensty(Per dice)	Iv	If=20mA	40		50	mcd
Spectrum With Of Half Value	△	If=20mA		30		nm
Wavelength	D	If=20mA	569		573	nm
Peak Forward Current(Per dice)1/10 Duty Cycle,0.1ms Pulse	Ifp	70				mA
Operating Temperature Range	Torp	-35℃～+85℃
Storage Temperature Range	Tstg	-35℃～+85℃
SolderTemperature 1.5mm below seating plane for 3 Seconds at 260℃
Absolute Maximum Rating at Ta=25℃
