4 Digit 14.2mm 7 Segment Custom LED Display Ultra Red Oven Control Application

Name: 4 Digit 142mm 7 Segment Custom LED Display Ultra Red Oven Control Application
Brand: LIGHTBO
Price: 1 USD

Buy cheap 4 Digit 14.2mm 7 Segment Custom LED Display Ultra Red Oven Control Application product

Brand Name : LIGHTBO

Model Number : LB40569AR1S

Certification : RoHS&SGS&ISO

Place of Origin : Shenzhen,China

MOQ : 1000PCS

Price : negotiable

Payment Terms : TT in advance& Western Union

Supply Ability : 50000PCS/Day

Delivery Time : 10-15Days

Packaging Details : EPE+CARTON

Package dimensions : 58.0 x 19 x 13.5mm

Character height : 14.2mm (0.56")

Polarity : Common anode

Colour : Ultra bright red

Wavelength : 620-630

Luminous intensity : 80-100mcd

Forward voltage : 1.8-2.3V/led

Forward current : 12-15mA/led

Operating temperature : 120C

Contact Now

Ultra Red Custom LED Display , 4 Digit 14.2mm 7 segment For oven control

Product descriptions:
Package dimensions: 58.0 x 19 x 13.5mm
Character height: 14.2mm (0.56")
Face colour: black face, white segments with film
Polarity: common anode
Working temperature: max + 120℃
Colour: ultra bright red
Wavelength: 620-630nm
Luminous intensity: 80-100mcd
Forward voltage: 1.8-2.3V/led
Emitting colours: available in red, blue, green, white, amber, orange

Product features:
High luminous intensity
Low power consumption
Stable performance
Continuous uniform segments
Big viewing angle
Long lifetime
Meet RoHS Compliant
Applications:
Ideal for home appliances, built-in oven control, multifunction digital oven timer control

Code:R- ultra bright red

Parameter	Symbol	Condition	Min	Typ	Max	Unit
Forward Voltage(Per dice)	Vf	If=20mA	1.8		2.3	V
Reverse Voltage(Per dice)	Vr	Ir=10uA	30			V
Luminous Intensty(Per dice)	Iv	If=20mA	80		100	mcd
Spectrum With Of Half Value	△λ	If=20mA		30		nm
Wavelength	Dλ	If=20mA	620		630	nm
LED working lifetime 100,000hrs Absolute Maximum Rating at Ta=25℃

Absolute Maximum Ratings(Ta=25℃)

Parameter	Symbol	Ratings	Unit
Forward Current(per dice)	Ipm	20	mA
Reverse Voltage(per dice)	Vr	5	V
Power Dissipation(per dice)	Pm	80	mW
Operating Temperature Range	Topr	-40～+120	℃
Storage Temperature Range	Tstg	-40～+120	℃
Solder Temperature(3 sec)	Th	260	℃
